| NEMA TEFC 低壓電機 OMN 143T-2 0.75kW 575V T |
| OMEC NORTH AMERICA INC |
|
|||||||
| NEMA? Motor | ||||||||
| Drawing No. | TEFC 143 145T | |||||||
| Customer : | ||||||||
| Client reference: | ||||||||
| Type:? | OMN 143T-2 | |||||||
| Brand : | OMEC | |||||||
| TYPICAL MOTOR PERFORMANCE DATA | ||||||||
| HP | kW | Pole | FL RPM | Frame | Voltage | Hz | Phase | FL Amps |
| 1 | 0.75 | 2 | 3460 | 143T | 575 | 60 | 3 | 1.16 |
| Enclosure | IP | Ins.Class | S.F. | Duty | NEMA Nom. Eff. |
NEMA Design |
kVA Code | Ambient (℃） |
| TEFC | 55 | F | 1.15 | CONT | 77 | B | K | 40 |
| Load | HP | kW | Amperes | Efficiency (%) | Power Factor | |||
| Full Load | 1 | 0.75 | 1.16 | 77 | 0.84 | |||
| Locked Rotor | 12 | |||||||
| Torque | Rotor wk2 Inertia (ib-ft2) |
|||||||
| Full Load (Ib-ft) |
Locked Rotor (% FLT) |
Break Down (% FLT) |
||||||
| 1.5 | 175 | 250 | ||||||
| Safe Stall Time(s) | Sound Pressure dB(A)@1M |
Bearings | Approx. Motor Weight (Ibs) |
|||||
| Cold | Hot | |||||||
| DE | NDE | |||||||
| 6205 2Z | 6203 2Z | |||||||
| *Bearings are the only Recommended spare part(s). | ||||||||
| Motor Options: | ||||||||
| Edition | ||||||||
| Performed | Checked | Date | ||||||
| Item | Changes | Performed | Checked | Date | ||||
